Electronic circuit part of the household electronic scale can not be debugged properly.
1. the effect tube of the electronic scale selects the pipe with a leakage current of 4-8mA. Indicates that the watt hour meter PAI has a full current of 50~200uA.
2. Resistors R1 and R2 use fine metal film resistors; potentiometers RP1 and RP3 use screw conditioning multi-loop potentiometers in order to carefully adjust the bridge balance.
3. other components show no special requirements.
The adjustment steps of the household electronic scale are as follows: when there is no load, adjust RP1 to make the pointer of the meter in the "0" position, and then place the object corresponding to the gauge component of the large measurement (such as gauge weight) on the electronic scale plate to adjust RP3 to make the pointer of the meter at the terminal of the electronic scale. The calibration of the linearity, the use of two-value gauge weights to stop correction, if the linearity is not good (especially in the two-value position L to re-select a good linear sliding potentiometer RP2. The error is too large, the demand is stopped by the weights of the standard components, and the scale of the instrument PA1 is re calibrated.
Household electronic scale belongs to a kind of weighing instrument, which uses Hooke's law or the lever balance principle of force to measure the quality of objects. Household electronic weighing scale is mainly composed of load-bearing fragments, such as weighing pan, weighing body, force transfer fragments such as leverage force transfer fragments, sensors and indicators fragmentary such as dial, electronic display instrument 3 parts. According to the principle of construction, it can be divided into three categories: mechanical scale.
Household electronic scale and Mechatronic scale
1. Seeing Accuracy: Some weighing scales are not accurate, not accurate in weighing, several measurements are different. Such a weight scale should not be purchased and should be weighed accurately.
2. Look at the big weighing: Different weighing scales have different weighing numbers, you should choose according to the details of your family, if there are big thin people will choose to weigh a larger number, so as not to exceed the large value, resulting in the scale can not be used.
3. Investigate how safe the scale is: when stepping on weighing, must have very good anti-skid maintenance measures, otherwise it is easy to skid on the air bricks in the home, causing risk. Therefore, we should have a good look at the effect of the bottom slip mat.
Shenzhen RESEE Technology Co., Ltd. is a R & D and production scale electronic scale business oriented technology oriented enterprises. The company's transformation from the beginning of 2005 to the present has a rich experience in the selection of microcontroller and standard chips, which can provide customers with the best products and the best service. The company acts as the agent of Hetai, Xinhai, Yikang, Songhan, Huarun, Sinosilicon Microelectronics, Sensor Core and other international well-known brands of products, can provide customers: 8-bit/32-bit MCU, LCD/LED/VFD driver, EEPROM memory, power management, clock circuit, Low-Power Operational amplifier, etc.Touch buttons and a series of standard IC and technical support. The company strives to research and develop electronic products in different fields. It can provide customers with self-confident Bluetooth scale scheme, Bluetooth four-electrode/eight-electrode alternating current lipid measurement scheme, Bluetooth direct current lipid measurement scheme, Bluetooth scheme, Bluetooth heart rate detection scheme, Bluetooth electric quantity detection scheme, common electronic scale scheme, fetal pressure gauge scheme, sphygmomanometer scheme. Infrared ear thermometer, electronic thermometer, LED power drive, touch switch, charger, movable power, alarm, bicycle meter, pedometer, thermocouple, battery power meter and other products of mature programs.
RESEE company has deep experience in developing various electronic solutions, sending off a wide range of customized development solutions. The company takes the market demand as the guidance, customer demand as its own responsibility, to do its utmost to provide customers with the latest market information, the best electronic scales and do quality service, in order to win-win customers and complete the sustainable operation for the pursuit of the purpose.
